Motor

• PMSM
• 3000W

Brake

• Break : Hydraulic, Drum Brake
• Parking Brake : Yes

Tyre

• Tyre : 4.00x12 MRF/CEAT

Controller

• Current rating : 3000W - 60VDC – 120 AMPS DC- IP65

Battery

• Type : Lithium
• Nominal Voltage : 64V
• Capacity : 230 Ah

Dimensions

• Length : 2915 mm
• Width : 1250 mm
• Height : 1850 mm

Weight

• Max Load Capacity : 759Kg
• Gross Vehicle Weight : 1116 kg
• Unladen Weight : 357 kg

Suspension

• Front Side : Front Fork Double Arm Suspension System
• Rear Side : Kaman/Leaf Spring with Shockers and Differential 42" Hydraulic

Ground Clearance

• 180 mm

Gradeability

• 7°

Max Speed

• 50-55 km/h

Range

• 200 km+

Charger

• Charger : 74V/45 A
• Duration of complete charging : 5 – 6 Hrs
